HRC55 Ball nose 4 flutes end mill solid tungsten carbide milling cutting tool cnc machine endmills cutter
Specifications:
1.Preferred tungsten steel base metal, large chip removal groove full grinding spiral groove,
2.It adopts precision machine tool to grind unique spiral edge angle, large core diameterdesignto enhance rigidity and earthquake resis- tance
3.Large chipremovalspace,not easy to accumulate chips, not easy to collapse, sharpandwear-resistant, and smooth chip cutting.Save time, lower breaking rate and improve the quality of hole wall.
4.The chamfer layout of the handle is easier to clamp, and the quality of laser marking is guaranteed.
5.Suitable for copper, carbon steel, alloy steel, cast iron, mold steel and other material. etc
| No | Size | Blade diameter | Blade length | Handle diameter | Total length | Flute |
| 1 | R0.5*2*D4*50L | 1.0 | 2 | 4 | 50 | 2 |
| 2 | R0.75*3*D4*50L | 1.5 | 3 | 4 | 50 | 2 |
| 3 | R1*4*D4*50L*D4 | 2.0 | 4 | 4 | 50 | 2 |
| 4 | R1.5*6*D4*50L | 3.0 | 6 | 4 | 50 | 2 |
| 5 | R2*8*D4*50L | 4.0 | 8 | 4 | 50 | 2 |
| 6 | R2.5*10*D6*50L | 5.0 | 10 | 6 | 50 | 2 |
| 7 | R3*12*D6*50L | 6.0 | 12 | 6 | 50 | 2 |
| 8 | R4*16*D8*60L | 8.0 | 16 | 8 | 60 | 2 |
| 9 | R5*20*D10*75L | 10.0 | 20 | 10 | 75 | 2 |
| 10 | R6*24*D12*75L | 12.0 | 24 | 12 | 75 | 2 |
| 11 | R1*4*D3*50L | 2.0 | 4 | 3 | 50 | 2 |
| 12 | R1.75*7*D4*50L | 3.5 | 7 | 4 | 50 | 2 |
| 13 | R2.5*10*D5*50L | 5.0 | 10 | 5 | 50 | 2 |
| 14 | R2*8*D4*75L | 4.0 | 8 | 4 | 75 | 2 |
| 15 | R3*12*D6*75L | 6.0 | 12 | 6 | 75 | 2 |
| 16 | R4*16*D8*75L | 8.0 | 16 | 8 | 75 | 2 |
| 17 | R2*8*D4*100L | 4.0 | 8 | 4 | 100 | 2 |
| 18 | R3*12*D6*100L | 6.0 | 12 | 6 | 100 | 2 |
| 19 | R4*16*D8*100L | 8.0 | 16 | 8 | 100 | 2 |
| 20 | R5*20*D10*100L | 10.0 | 20 | 10 | 100 | 2 |
| 21 | R6*24*D12*100L | 12.0 | 24 | 12 | 100 | 2 |
| 22 | R7*28**D14*100L | 14 | 28.0 | 14 | 100 | 2 |
| 23 | R8*32*D16*100L | 16 | 32.0 | 16 | 100 | 2 |
| 24 | R9*36*D18*100L | 18 | 36.0 | 18 | 100 | 2 |
| 25 | R10*40*D20*100L | 20 | 40.0 | 20 | 100 | 2 |
| 26 | R3*12*D6*150L | 6 | 12.0 | 6 | 150 | 2 |
| 27 | R4*16*D8*150L | 8 | 16.0 | 8 | 150 | 2 |
| 28 | R5*20*D10*150L | 10 | 20.0 | 10 | 150 | 2 |
| 29 | R6*24*D12*150L | 12 | 24.0 | 12 | 150 | 2 |
| 30 | R7*28*D14*150L | 14 | 28.0 | 14 | 150 | 2 |
| 31 | R8*32*D16*150L | 16 | 32.0 | 16 | 150 | 2 |
| 32 | R9*36*D18*150L | 18 | 36.0 | 18 | 150 | 2 |
| 33 | R10*40*D20*150L | 20 | 40.0 | 20 | 150 | 2 |
Material
Tungsten carbide
Flexural Strength
2500-5000n/mm2
Length
50-200mm (As your requirement)
Diameter
1mm-50mm (As your requirement)
Coating
Tin, Altin, Nano, Tisin
Package
Protective sleeve+ plastic
Note:
These sizes we have in stock, and the other sizes,we can produce for you based on your requirements. Any need, please free comments.
